Industrial Air Hose
In short
Braided compressed-air hose for workshops and pneumatic tools, 20 bar working pressure.
ISO 9001
Request a Quote →
Technical specifications
Working pressure 20 bar
Burst pressure ≥ 60 bar
Temperature range -20 °C … +70 °C
Inner diameter 6 – 25 mm
Reinforcement textile braid
Cover SBR/NBR, oil-mist & abrasion resistant
Applications
- Workshop air lines
- Pneumatic tools
- Plant air distribution
- Spray and blow-off stations
Construction
- Tube: smooth SBR/NBR rubber, oil-mist resistant
- Reinforcement: high-tenacity textile braid
- Cover: abrasion-resistant SBR/NBR, oil resistant
Sizes & dimensions
Inner Ø / Outer ØWorking pressure · Weight
6 mm / 13 mm20 bar · 0.18 kg/m
10 mm / 18 mm20 bar · 0.27 kg/m
13 mm / 22 mm20 bar · 0.36 kg/m
25 mm / 37 mm16 bar · 0.70 kg/m
Other diameters and lengths produced on request.
Frequently asked questions
Yes. The SBR/NBR liner and cover tolerate the oil-mist found in lubricated compressor air without hardening over time.
